OA1000Pro Rfid/FP Linux

Time attendance Anviz OA1000Pro: Fingerprint / Rfid attendance terminal, Linux operating system and with photo shooting.

OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN
OA1000Pro Rfid/Bio LinuxEN

OA1000Pro is an Anviz fingerprint identification flagship product, based on the Linux operating system, featuring: dual-core high-speed CPU; large memory support; and 1: 10000 matching speed of less than 0.5 seconds. Take advantage of flexible networking with a variety of network connections: TCP/IP, WIFI or 3G communication modules (optional). The OA1000Pro features a built-in webserver, allowing convenient access to the device settings and record searching. OA1000Pro with Anviz Crosschex Cloud system, reduces the cost of system configuration and the mobile APP provide the great flexibility for enterprise management.











Functions and equipment

Biometric fingerprint reader
RFID card reader
PIN code
Camera
Web server
LAN network card
Wifi
USB pen drive
Ringtones
Management software

Features

  1. Dual Core high speed CPU, large memory support 10,000 FP Templates
  2. Less than 0.5s rapidly verification speed (1:10,000)
  3. 1.3Million Camera capture verifier’s photo for event backup
  4. Internal Webserver for device quick set and records check
  5. TCP/IP, WIFI, 3G and RS485 multi communication modes
  6. Dual Relays both for door control and linkage with alarm system
  7. Provide complete Development Kit to build exclusive application platform(SDK, EDK, SOAP)
  8. Supports a variety of third-party modules, to meet different project requirement(Mercury, U.ARE.U, HID iClass)

Tecnology

  • Sensor                          AFOS
  • Algorithm                  Anviz BioNANO
  • User Capacity                  10,000
  • Fingerprint Template Capacity 10,000
  • Scan Area(W * H)          18mm * 22mm
  • Dimensions(W * H * D)          180 * 137 * 40mm
  • Log Capacity                  200,000
  • Comm                          TCP/IP, RS232, USB Flash Drive Host, Optional WIFI, 3G
  • Relay                          2 Relays Output (Directly Lock control & Alarm output
  • I/O                          Wiegand In&Out, Switch, Door Bell
  • FRR                          0.001%
  • FAR                          0.001%
  • User Photo Capacity          500 Support 16G SD card
  • Support RFID Card          125KHZ EM Option 13.56MHZ Mifare , HID iClass
  • Webserver                  Built-in Webserver
  • Image Display                  User Photo & Fingerprint Image
  • Short Message                  200
  • Scheduled Bell                  30 Scheduleds
  • Self-service Record Inquiry Yes
  • Groups & Time Schedules          16 Groups, 32 Time Zones
  • Certificate                  FCC, CE, ROHS
  • Tamper Alarms                  Yes
  • Operating Voltage          DC 12V
  • Temperature                  -20℃~ 60℃
  • Preferred Humidity          10 to 90%
  • Firmware Upda                  USB Flash Drive, TCP/IP, Webserver
  • Processor                  Dual Core 1.0GHZ High Speed Processor
  • Memory                          8G Flash Memory & 1G SDRAM
  • Resolution                  500 DPI
  • LCD                          3.5 Inch TFT Display
  • Camera                    0.3 Million Pixel Cameras



Functions and equipment

Biometric fingerprint reader
RFID card reader
PIN code
Camera
Web server
LAN network card
Wifi
USB pen drive
Ringtones
Management software

Applications
